CP7755 1/2in Air Flex Mini

Stock Code:
CP7755
Regular Price:
$1,239.00 excl. GST

Description

The CP7755 series offers adjustable power control for Air tools (11 settings in fwd) and allows operators to choose the torque depending on application. Due to its patented Air Flex mini air inlet, this 1/2” impact wrench allows maneuverability.

The CP7755 Series 1/2" impact wrench allows operators to select the right power with 11 settings in forward on its innovative adjustable power control. The hose is no longer an issue thanks to the integrated pneumatic flex mini pneumatic inlet. The series delivers reverse torque up to 960 ft.lbs.

Technical Specifications
Max working torque fwd 575 Nm
Max torque reverse 1300 Nm
Min working torque fwd 80 Nm
Torque limited No
Air inlet thread size (in) 1/2
Max dynamic air working pressure 6.3 bar
Min hose diam (16 ft hose length) 0.38 in
Min hose diam (5 m hose length) 10 mm
Sound Power 105 dB(A)
Sound Pressure 94 dB(A)
Uncertainty vibration-K 3.4 m/s²
Free Speed 7700 rpm
Air consumption at free speed 2.6 l/s
Height (H) 205 mm
Length (L) 169 mm
Width (W) 76 mm
Power weight ratio 670 Nm/kg
Side to Center 38 mm
Weight 1.93 kg
Blow per minute 1200
Body Composite
Handle type Pistol
Impact mecanism Twin hammer
Output drive size (in) 1/2
Output drive type Sq
Output retainer type Friction ring
Starting system Trigger
